H05VV-F PVC Flexible Multi Core Cable CPR Compliance

Haoguang VDE H05VV-F PVC Flexible Multi Core Cable CPR Compliance is suitable for the household appliances, plant and machinery,wiring purpose and for manufacturing cords.The outer sheath provided here is special PVC,self-extinguishing and flame retardant. The PVC jacket provide increased protection against hot surfaces, offering resistance to abrasion and cutting. Bare copper, fine wire conductor,2 cores and 3 cores options for you. Rated voltages is 300/500V.

Send Inquiry

Product Description

1.Product Introduction of H05VV-F PVC Flexible Multi Core Cable CPR Compliance


Haoguang VDE H05VV-F PVC Flexible Multi Core Cable CPR Compliance is suitable for the household appliances, plant and machinery,wiring purpose and for manufacturing cords.The outer sheath provided here is special PVC,self-extinguishing and flame retardant.The PVC jacket provide increased protection against hot surfaces, offering resistance to abrasion and cutting. Bare copper, fine wire conductor,There are 2 cores and 3 cores options for you.




2.Product Parameter (Specification) of H05VV-F PVC Flexible Multi Core Cable CPR Compliance


Rated Voltage: 300/500V
Rated Temperature: 70℃
Standard: DIN EN50525

Size

No. x  mm2

Structure of Conductor

No./mm

Insulation Thickness

mm

Sheath Nominal Thickness

mm

Outside Diameter

(mm)

Insulation Resistance at 70 ℃ Max

Min

Max

MΩ. km

2 x 0.75

24/0.20

0.6

0.8

5.7

7.2

0.011

42/0.15

2 x 1.0

32/0.20

0.6

0.8

5.9

7.5

0.010

2 x 1.5

28/0.15

0.7

0.8

6.8

8.6

0.010

2 x 2.5

42/0.15

0.8

1.0

8.4

10.6

0.009

3 x 0.75

24/0.20

0.6

0.8

6.0

7.6

0.011

42/0.15

3 x 1.0

32/0.20

0.6

0.8

6.3

8.0

0.010

3 x 1.5

48/0.20

0.7

0.9

7.4

9.4

0.010

3 x 2.5

51/0.25

0.8

1.1

9.2

11.4

0.009



3 Product Feature of the H05VV-F PVC Flexible Multi Core Cable CPR Compliance



1) Conductor: Stranded bare copper wire.
2) Insulation: PVC.
3) Jacket: PVC.




4 Product detail of the H05VV-F PVC Flexible Multi Core Cable CPR Compliance



1) Conditionally resistant to water,oils,acids,alkali.
2) Standard sizes and custom color available upon request (black, red, yellow,orange,green,white…).
3) Excellent resistance to abrasion, deformation.
4) RoHS compliance.
5) Brand: Haoguang.



5 Packaging & Delivery



1) Packaging Details:

It is determined by the quantity and requirements you purchase.  Can be negotiated.



2) Port: Ningbo



Delivery: By Sea, By Air, By express.








6 FAQ:



1) Can I use our private packaging,LOGO on your products ?

Yes.Our professional team will give you advice for customised plan and could send you quotes within 3 working days while receiving your inquiry.



2) How can I get samples?

Please tell us the detailed information of products you need. Then we will check our stock.we can offer the samples immediately. If we don’t have the exact model you need, maybe we will send you similar sample if you accept. If you couldn’t accept, it will need 3~5 days to arrange sample developing.



3) What is your shipping method?

Small order will be shipped by DHL, Fedex,TNT,UPS; Bulk order shipped by sea/train/air.
