VDE H03VVH2-F PVC Multi Core 300V Power Cable
  • Air ProVDE H03VVH2-F PVC Multi Core 300V Power Cable
  • Air ProVDE H03VVH2-F PVC Multi Core 300V Power Cable

VDE H03VVH2-F PVC Multi Core 300V Power Cable

Haoguang VDE H03VVH2-F PVC Multi Core 300V Power Cable is suitable for the household appliances, plant and machinery,wiring purpose and for manufacturing cords.The outer sheath provided here is special PVC,self-extinguishing and flame retardant.The PVC jacket provide increased protection against hot surfaces, offering resistance to abrasion and cutting. Bare copper, fine wire conductor. Rated voltages is 300/300V. Contact our technical team to discuss your specitic project or application requirements.

Send Inquiry

Product Description

1.Introduction of VDE H03VVH2-F PVC Multi Core 300V Power Cable


Haoguang VDE H03VVH2-F PVC multi core power cable is suitable for the household appliances, plant and machinery,wiring purpose and for manufacturing cords.The outer sheath provided here is special PVC,self-extinguishing and flame retardant.The PVC jacket provide increased protection against hot surfaces, offering resistance to abrasion and cutting. Bare copper, fine wire conductor.




2.Parameter (Specification) of VDE H03VVH2-F PVC Multi Core 300V Power Cable


Rated Voltage: 300/300V
Rated Temperature: 70℃
Standard: DIN EN50525

Size

No. x  mm2

Structure of Conductor

No./mm

Insulation Thickness

mm

Sheath Nominal Thickness

mm

Outside Diameter

(mm)

Insulation Resistance at 70 ℃ Max

Min

Max

MΩ. km

2 x 0.5

16/0.20

0.5

0.6

4.6

5.9

0.012

28/0.15

3*4.9

3.7*5.9

2 x 0.75

24/0.20

0.5

0.6

4.9

6.3

0.01

42/0.15

3.2*5.2

3.8*6.3

3 x 0.5

16/0.20

0.5

0.6

4.9

6.3

0.012

28/0.15

3 x 0.75

24/0.20

0.5

0.6

5.2

6.7

0.01

42/0.15



3.Feature of the VDE H03VVH2-F PVC Multi Core 300V Power Cable



1) Conductor: Stranded bare copper wire.
2) Insulation: PVC.
3) Jacket: PVC.




4.Detail of the VDE H03VVH2-F PVC Multi Core 300V Power Cable



1) Conditionally resistant to water,oils,acids,alkali.
2) Standard sizes and custom color available upon request (black, red, yellow,orange,green,white…).
3) Excellent resistance to abrasion, deformation.
4) RoHS compliance.
5) Brand: Haoguang.



5 Packaging & Delivery



1) Packaging Details:

It is determined by the quantity and requirements you purchase.  Can be negotiated.



2) Port: Ningbo



Delivery: By Sea, By Air, By express.








6 FAQ:



1) Where is your factory located?

Add: No.226 Changing Road Xizhou,Xiangshan County,Zhejiang,China.



2) How can I get samples?

Please tell us the detailed information of products you need. Then we will check our stock.we can offer the samples immediately. If we don’t have the exact model you need, maybe we will send you similar sample if you accept. If you couldn’t accept, it will need 3~5 days to arrange sample developing.



3) Is the quality of VDE H03VVH2-F PVC Multi Core 300V Power Cable guaranteed?

Yes, the quality of our products is highly guaranteed. Our workshops are equipped with advanced machines and test equipment, and our workers are highly experienced. We strictly follow the international standards and customers’ requirements.



7 FACTORY :




8 Other Products :

Hot Tags: VDE H03VVH2-F PVC Multi Core 300V Power Cable, Manufacturers, Suppliers, Wholesale, Buy, Factory, Customized, In Stock, Bulk, Free Sample, Brands, China, Made in China, Exporter, Zhejiang, Ningbo, Cheap, Discount, Low Price, Buy Discount, Price, Price List, Quotation, OEM, Newest, Quality, Hot Sale, Durable, Latest Selling
