We provide UL 3135 Silicone Rubber Single Core Cable for Appliance with coils and reel package with UL certification File Number E192545. 1000ft or 2000ft per coil,from 14AWG to 24AWG,suitable for internal leading wire of household appliance, industrial machines,electronic products,automation equipment,medical equipment and lightings. Established in 1996,Haoguang cable has been focusing on production of wire and cable for over 25 years.Purchase silicone wire cable,please contact Haoguang,the reliable cable manufacturer. OEM service is available.
1.Introduction of UL 3135 Silicone Rubber Single Core Cable for Appliance
This is our first UL product started in 1998. UL File number is E192545. UL 3135 Silicone Rubber Single Core Cable for Appliance accompany our factory grow up over 20 years.
Application :
This Cable is suitable for internal wiring for Appliance which need high temperature and long-term reliable cable, such as household appliance, lightings,heaters,robots and industrial machines. The cable is comply with Rohs2.0 Directive and the 201 SVHC under Regulation of REACH.
2.Parameter (Specification) of UL 3135 Silicone Rubber Single Core Cable for Appliance
Rated Voltage: 600V
Rated Temperature: from -60℃ to 200℃
Standard: UL758
|
Spec AWG |
Structure of Conductor NO./mm |
Outer Diameter mm |
Package M per coil |
Conductor Resistance at 20 ℃ Max Ω／km |
|
24 |
1/0.52 TC |
2.1 |
610 |
94.2 |
|
22 |
1/0.65TC |
2.2 |
305 |
59.4 |
|
20 |
1/0.813 TC |
2.4 |
305 |
36.7 |
|
18 |
7/0.39TC |
2.75 |
305 |
23.2 |
|
16 |
7/0.49 TC |
3.05 |
305 |
14.6 |
|
14 |
7/0.62TC |
3.45 |
305 |
8.96 |
3.Feature of the UL 3135 Silicone Rubber Single Core Cable for Appliance
1) Packed with UL Label and Tag.
2) Can be used in -60℃ to 200℃.
3) Full colour range. White, Black, Blue, Brown, Red, Green, Yellow/Green, Yellow and others.
4) High quality. Comply with the UL standards, each coil with UL Label and Tag.
5) Flexible order quantity. MOQ around 10000 meter for new order, We can supply the cable to meet customer's requirement. But if we have stock, even 1 coil is acceptable for shipping.
4.Detail of the UL 3135 Silicone Rubber Single Core Cable for Appliance
1) The cable is made from Tinned Copper Wire which is pure Oxigen free copper. According the UL standards, the single tinned copper wire diameter is not less than 0.38mm.
2) Insulation is Silicone Rubber.
3) Long lasting stability.
4) Brand: Haoguang.
5 Packaging & Delivery
1) Packaging Details:
It is determined by the quantity and requirements you purchase. Can be negotiated.
2) Port: Ningbo
Delivery: By Sea, By Air, By express.
6 FAQ:
1) Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last.
2) Can I order the cable/wire which is lower than your MOQ?
First, we will check the inventory.if it is in stock, sure, it’s ok! But if it was out of stock.when your quantity is close to our MOQ, it’s OK. If it is much less than MOQ, maybe we will take it as a sample order, the price will be different.
3) Can I get a discount?
It depends on your quantity. Pls contact us for more detail information.
