H07V-K H07V-U Flexible PVC Normal Hook-up Wire

Haoguang H07V-K H07V-U Flexible PVC Normal Hook-up Wire is designed for power installation fixed wiring or flexible connection for electrical appliances and household appliances, with rated voltage up to 450/750V. Oxygen free, VDE certified, Unparalleled performance,stable quality and abrasion resistance.

Send Inquiry

Product Description

1.Introduction of H07V-K H07V-U Flexible PVC Normal Hook-up Wire


Haoguang H07V-K H07V-U Flexible PVC Normal Hook-up Wire is designed for power installation fixed wiring or flexible connection for electrical appliances and household appliances, with rated voltage up to 450/750V. Oxygen free copper conductor, VDE certified, Unparalleled performance,stable quality and abrasion resistance.




2.Product Parameter (Specification) of H07V-K H07V-U Flexible PVC Normal Hook-up Wire


Rated Voltage: 450/750V
Rated Temperature: +70℃
Standard: DIN EN50525

Type

Conductor

Insulation Conductor

Electrical Characteristic

Nominal Area
mm

Structure of Conductor
No./mm

Insulation Thickness
mm

Overall Diameter
(mm)

Conductor Resistance at 20  Max

Min

Max

Ωkm

H07V-U

1.5

1/1.38

0.7

2.6

3.2

12.1

2.5

1/1.78

0.8

3.2

3.9

7.41

4

1/2.25

0.8

3.6

4.4

4.61

6

1/2.76

0.8

4.1

5

3.08

10

1/3.56

1.0

5.3

6.4

1.83

H07V-K

1.5

48/0.2

0.7

2.8

3.4

13.3

30/0.25

2.5

51/0.25

0.8

3.4

4.1

7.98

4

57/0.30

0.8

3.9

4.8

4.95

6

84/0.30

0.8

4.4

5.3

3.3

10

84/0.40

1.0

5.7

6.8

1.91



3 Product Feature of the H07V-K H07V-U Flexible PVC Normal Hook-up Wire



1) Materials: Stranded bare copper, High precision non-oxygen tinned copper.
2) Insulation: Premium Grade Flame Retardant Polyvinyl Chloride( PVC).




4 Product detail of the H07V-K H07V-U Flexible PVC Normal Hook-up Wire



2) High resistance to many different chemical substances chemical resistant.
3) Standard sizes and custom color available upon request (black, red, yellow,orange,green,white…).
5) RoHS compliant.
7) Brand: Haoguang.



5 Packaging & Delivery



1) Packaging Details:

It is determined by the quantity and requirements you purchase.  Can be negotiated.



2) Port: Ningbo



Delivery: By Sea, By Air, By express.








6 FAQ:



1) Why PVC insulation ?

Polyvinyl Chloride (PVC) insulated and sheathed cables are used in a wide variety of applications from fixed wiring to flexible installations. They are available in a number of sizes, colors and conductor materials. PVC properties make it suitable for applications where the cables may be exposed to extremely high or low temperatures, providing protection against degradation.



2) Could we provide the free sample for customer?

Yes, we could provide the free sample for customer for checking.



3) When I want customized H07V-K H07V-U Flexible PVC Normal Hook-up Wire, how to do?

We have professional service team, OEM & customized service is welcome. Drawings / samples are required.
